10" Stationary Table Saw

PCB270TS

FEATURES SPECIFICATIONS


  • Easy mobility of saw with the One Step caster system


  • Table top bevel scale provides accurate blade settings


  • Upfront separate bevel and height blade handles for easy access


  • Precision ground Cast Iron Work surface with 30" Right rip capacity


  • Powerful dual voltage 15.0/7.5 Amp ball bearing motor


  • Built-in arbor lock for quick blade changes


  • Rip fence has micro adjustment features for precision settings


  • 2-1/2" dust port with shrouded blade provide hookup to shop vacuums


  • Machined 3/4" miter t-slots for use with indexing miter gauge or option accessories


  • Motor: 15/7.5 Amp (120/240V)


  • Blade Diameter: 10 "


  • Blade Speed: 3450 rpm


  • Arbor Size: 5/8 "


  • Miter Gauge Groove: 3/4


  • Chip Exhaust Opening: 2-1/2 "


  • Depth of Cut at 90┬░: 3-1/2 "


  • Table Height: 38-9/16" "


  • Depth of Cut at 45┬░: 2-1/4 "


  • Table Size: 27-1/8x20-1/8 "


  • Max Rip To Right Of Blade: 30 "


  • Max Rip To Left Of Blade: 18 "


  • Length: 27-1/8" "


  • Width: 20-1/8" "


  • Max Width of Dado: 13/16 "


  • Height: 38-9/16 "


  • Shipping Weight: 238.56 lbs


  • Weight: 220.59 lbs
