10" JobSite Table Saw

PCB220TS

FEATURES SPECIFICATIONS


  • Mobile stand folds quicky for storage or transport to worksite on 8" wheels


  • Large die-cast aluminum for stable work support surface


  • Right side extension table provides up to 24-1/2" rip capacity


  • Shrouded blade with 2-1/2" port, keeps workshop clean


  • Indexing Miter Gauge has 3/4" t-slots for accurate crosscuts


  • Two blade adjustment handles provide accurate height and bevel settings


  • Steel out-feed support for extra support on long workpieces


  • Built-in storage for Miter, Fence, Guard Assembly, cord and push stick


  • Motor: 15 Amp


  • Blade Diameter: 10 "


  • Arbor Size: 5/8 "


  • Blade Speed: 5000 rpm


  • Miter Gauge Groove: 3/4"


  • Chip Exhaust Opening: 2-1/2 "


  • Depth of Cut at 90┬░: 3 "


  • Table Height: 35 "


  • Depth of Cut at 45┬░: 2-1/2 "


  • Max Rip To Right Of Blade: 24-1/2 "


  • Table Size: 25 x 19-1/2 "


  • Max Rip To Left Of Blade: 10 "


  • Length: 25 "


  • Width: 19.5 "


  • Max Width of Dado: 1/2 "


  • Height: 35 "


  • Weight: 73.76 lbs


  • Shipping Weight: 85.46 lbs
