Jointer

PC160JT

FEATURES SPECIFICATIONS


  • Variable 6,000 to 11,000 rpm Speed Range allows the user to select the right speed for the size and hardness of material being cut


  • Two knife cutter head with jack screw knife leveling arrangement for easy replacement and adjustment of knives


  • Built-in cutter head lock facilitates knife replacement and adjustment


  • Extra large table provides ample work support and surfacing stock up to a full 6" wide


  • Center mounted fence gives needed support throughout the cut for accurate edge jointing


  • Motor: 10A, 120V AC, 60Hz


  • Cut Capacity - Width: 6-1/8" "


  • Cut Capacity - Depth: 1/8" "


  • Cutterhead Speed: 12,000 to 22,000 CPM, Variable Speed 6,000 to 11,000 rpm rpm


  • Number of Knives: 2


  • Cutterhead Diameter: 3 "


  • Table Length: 30 "


  • Table Length of Front Table (Infeed): 15 "


  • Table Length of Rear Table (Outfeed): 15 "


  • Table Width: 6-3/16" "


  • Table Height: 13-1/2 "


  • Fence Size: 4-1/4" x 19-3/4" "


  • Fence Tilt: 0 to 45 °


  • Fence Positive Stops: 90° and 45° °


  • Dust Port Diameter: 4 "


  • Length: 30 "


  • Width: 18 "


  • Height: 13-1/2 "


  • Weight: 35 lbs


  • Shipping Weight: 40 lbs
