  • • PORTER-CABLE's Lithium Ion batteries provide extended run time in both their LX series and EX series. PORTER-CABLE's Lithium Ion batteries deliver a compact lightweight platform to minimize fatigue.

    • To ensure reliability the batteries have virtually no self discharge so they are ready to go even after an extended period of time. The battery will provide full power until it fully discharges ensuring maximum performance with each charge.

    • All PORTER-CABLE 18V Lithium Ion batteries work with all PORTER-CABLE 18V Tools.

    18V LX Lithium Ion Battery - PC18BLX
    • The LX series of Lithium Ion batteries are our most lightweight and compact 18V batteries minimizing fatigue and allowing users to operate in tight areas.

    • 30 Minute Charge Time




    18V EX Lithium Ion Battery - PC18BLEX
    • The EX series of Lithium Ion batteries provide more power and runtime. These batteries are ideal for use with heavy tools such as circular saws, reciprocating saws, and drill/drivers in heavy drilling applications.

    • 60 Minute Charge Time

    Multi-Chemistry Slide Pack Charger - PCXMVC
    • Charges any PORTER-CABLE 18V NiCd or Lithium Ion battery



  • PORTER-CABLE’s NiCD batteries provide the user with the best value and are more reliable due to their ability to operate in hot and cold temperatures.


    18V NiCD Battery - PC18B
    • 60 Minute charge-time





    18V NiCD Battery - PC18B-2
    • High output nickel cadmium battery cells with "no memory" technology provide up to 500 recharges

    • 60 Minute charge-time

    Multi-Chemistry Slide Pack Charger - PCXMVC
    • Charges any PORTER-CABLE 18V NiCd or Lithium Ion battery


  • PORTER-CABLE’s 12 Volt MAX† Lithium Ion line of cordless power tools offers durability, compact size and lightweight for professionals that demand quality at a great value.
    12V Max† Compact Lithium Ion 3/8 in. Drill/Driver - PCL120DDC-2
    • Two-Speed Gearbox (0-315/0-1200)
    • Magnetic Bit Tip Holder
    • L.E.D. Worklight
    • Belt Hook


    12V Max† Compact Lithium Ion 1/4 in. Hex Impact Driver - PCL120IDC-2
    • Quick-Release 1/4 in. Hex Chuck
    • Variable Speed Trigger (0-2,400 RPM)
    • L.E.D. Worklight
    • Belt Hook


    12V Max† Compact Lithium Ion ClampSaw - PCL120CRC-2
    • Adjustable Clamping Shoe with 2 in. Outer Diameter Capacity
    • Tool Free Blade Release
    • Pivoting Handle 0, 45, and 90º
    • Variable Speed Trigger (0-3,000 SPM)

    12V Max† Compact Lithium 2-Tool Kit - PCL212IDC-2
    • Drill/driver’s 2-speed gearbox allows for high-speed drilling (0-315 / 0-1,200 RPM) & high-torque fastening (220 in.-lbs. max torque)
    • Impact Driver delivers delivers 950 in-lbs torque without kick-back


    12V Max† Compact Lithium Ion Battery - PCL12BLX
    • Lithium Ion battery holds charge for extended periods, so packs are ready to go even after being stored




    12V Max† Compact Lithium Ion Fast Charger - PCL12C
    • Lithium Ion battery holds charge for extended periods, so packs are ready to go even after being stored
    • 30 minute charge time*


    †Maximum initial battery voltage (measured without a workload) is 12 volts. Nominal voltage is 10.8.
    *80 Capacity for PCL12BLX Lithium Ion Batteries.
  • Important Charging Notes

    Longest life and best performance can be obtained if the battery pack is charged when the air temperature is between 65°F and 75°F (18°- 24°C). DO NOT charge the battery pack in an air temperature below +40°F (+4.5°C), or above +105°F (+40.5°C). This is important and will prevent serious damage to the battery pack.

    The charger and battery pack may become warm to touch while charging. This is a normal condition, and does not indicate a problem. To facilitate the cooling of the battery pack after use, avoid placing the charger or battery pack in a warm environment such as in a metal shed, or an uninsulated trailer.


    If the battery pack does not charge properly:

    a. Check current at receptacle by plugging in a lamp or other appliance

    b. Check to see if receptacle is connected to a light switch which turns power off when you turn out the lights.

    c. Move charger and battery pack to a location where the surrounding air temperature is approximately 65°F - 75°F (18°- 24°C).

    d. If charging problems persist, take the tool, battery pack and charger to your local service center.

    The battery pack should be recharged when it fails to produce sufficient power on jobs which were easily done previously. DO NOT CONTINUE to use under these conditions. Follow the charging procedure. You may also charge a partially used pack whenever you desire with no adverse affect on the battery pack.

    Foreign materials of a conductive nature such as, but not limited to, steel wool, aluminum foil, or any buildup of metallic particles should be kept away from charger cavities. Always unplug the charger from the power supply when there is no battery pack in the cavity. Unplug charger before attempting to clean.

    Do not freeze or immerse charger in water or any other liquid.

    Leaving the Battery in the Charger
    The charger and battery pack can be left connected with the LED glowing indefinitely. PORTER-CABLE chargers feature an automatic tune-up mode which equals or balances the individual cells in the battery pack to allow it to function at peak capacity.

    Battery packs should be tuned up weekly or whenever the battery no longer delivers the same amount of work.

    To use the automatic tune-up mode, place the battery pack in the charger and leave it for at least 8 hours.

    The charger will keep the battery pack fresh and fully charged.

    Storage Recommendations
    The best storage place is one that is cool and dry away from direct sunlight and excess heat or cold.

    Long storage will not harm the battery pack or charger.
